Mast Chains
Mast Chains - Used in different applications, leaf chains are regulated by ANSI. They can be used for forklift masts, as balancers between heads and counterweight in several machine tools, and for tension linkage and low-speed pulling. Leaf chains are sometimes likewise known as Balance Chains.
Construction and Features
Made of a simple link plate and pin construction, steel leaf chains is identified by a number which refers to the pitch and the lacing of the links. The chains have particular features like for instance high tensile strength for each section area, which allows the design of smaller mechanisms. There are B- and A+ kind chains in this particular series and both the AL6 and BL6 Series include the same pitch as RS60. Lastly, these chains cannot be powered using sprockets.
Selection and Handling
Comparably, in roller chains, all of the link plates have higher fatigue resistance because of the compressive stress of press fits, whereas in leaf chains, only two outer plates are press fit. The tensile strength of leaf chains is high and the maximum acceptable tension is low. If handling leaf chains it is essential to confer with the manufacturer's catalogue to be able to guarantee the safety factor is outlined and utilize safety measures all the time. It is a better idea to carry out extreme caution and utilize extra safety guards in applications wherein the consequences of chain failure are severe.
Higher tensile strength is a direct correlation to the utilization of a lot more plates. Since the utilization of a lot more plates does not enhance the most permissible tension directly, the number of plates could be restricted. The chains require regular lubrication as the pins link directly on the plates, producing a really high bearing pressure. Using a SAE 30 or 40 machine oil is frequently advised for the majority of applications. If the chain is cycled more than one thousand times every day or if the chain speed is over 30m for each minute, it will wear very fast, even with continual lubrication. Thus, in either of these situations the use of RS Roller Chains would be more suitable.
The AL-type of chains should only be used under particular situations like for example when wear is really not a huge problem, if there are no shock loads, the number of cycles does not go beyond a hundred a day. The BL-type will be better suited under other conditions.
The stress load in parts will become higher if a chain using a lower safety factor is chosen. If the chain is likewise utilized amongst corrosive situations, it could easily fatigue and break really fast. Doing regular maintenance is important if operating under these types of conditions.
The type of end link of the chain, whether it is an outer link or inner link, determines the shape of the clevis. Clevis connectors or otherwise called Clevis pins are made by manufacturers but often, the user provides the clevis. A wrongly constructed clevis can reduce the working life of the chain. The strands should be finished to length by the producer. Check the ANSI standard or phone the producer.
