Throttle Body for Forklift
Forklift Throttle Body - Where fuel injected engines are concerned, the throttle body is the component of the air intake system which controls the amount of air which flows into the motor. This particular mechanism operates in response to driver accelerator pedal input in the main. Usually, the throttle body is placed between the intake manifold and the air filter box. It is normally connected to or placed close to the mass airflow sensor. The largest piece inside the throttle body is a butterfly valve called the throttle plate. The throttle plate's main task is so as to control air flow.
On several styles of vehicles, the accelerator pedal motion is communicated via the throttle cable. This activates the throttle linkages which in turn move the throttle plate. In vehicles consisting of electronic throttle control, otherwise known as "drive-by-wire" an electric motor regulates the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This particular sensor sends the pedal position to the ECU or Engine Control Unit. The ECU is responsible for determining the throttle opening based on accelerator pedal position along with inputs from different engine sensors. The throttle body has a throttle position sensor. The throttle cable connects to the black part on the left hand side which is curved in design. The copper coil situated near this is what returns the throttle body to its idle position when the pedal is released.
The throttle plate rotates inside the throttle body every time the operator presses on the accelerator pedal. This opens the throttle passage and permits much more air to be able to flow into the intake manifold. Typically, an airflow sensor measures this alteration and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors to be able to produce the desired air-fuel ratio. Often a throttle position sensor or otherwise called TPS is attached to the shaft of the throttle plate to provide the ECU with information on whether the throttle is in the idle position, the wide-open position or also called "WOT" position or somewhere in between these two extremes.
In order to regulate the least amount of air flow while idling, several throttle bodies may include adjustments and valves. Even in units that are not "drive-by-wire" there would usually be a small electric motor driven valve, the Idle Air Control Valve or IACV which the ECU uses to be able to control the amount of air which could bypass the main throttle opening.
It is common that several automobiles have one throttle body, even if, more than one can be used and attached together by linkages in order to improve throttle response. High performance cars like for example the BMW M1, along with high performance motorcycles like for instance the Suzuki Hayabusa have a separate throttle body for every cylinder. These models are called ITBs or "individual throttle bodies."
The throttle body and the carburator in a non-injected engine are somewhat the same. The carburator combines the functionality of both the fuel injectors and the throttle body into one. They could modulate the amount of air flow and mix the fuel and air together. Automobiles which have throttle body injection, which is referred to as TBI by GM and CFI by Ford, situate the fuel injectors in the throttle body. This allows an older engine the chance to be transformed from carburetor to fuel injection without really changing the design of the engine.
